20.22.9.024.4000 Relay, DPST-NO, 250VAC, 16A Finder

FINDERSKU:20.22.9.024.4000 Bestelcode:4179663

Prijs:
Actie prijs€54,44

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (14 units)

Documenten en downloads

Omschrijving

FINDER - 20.22.9.024.4000 - Power Relay, DPST-NO, 24 VDC, 16 A, 20 Series, DIN Rail

  • Contact Configuration: DPST-NO
  • Coil Voltage: 24VDC
  • Contact Current: 16A
  • Product Range: 20 Series
  • Relay Mounting: DIN Rail
  • Coil Type: -
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Screw
  • Contact Voltage VDC: -
  • Contact Material: Silver Tin Oxide
  • Coil Resistance: 105ohm
  • SVHC: No SVHC (15-Jan-2019)
  • Coil Current: 230mA
  • Coil Voltage VDC Nom: 24V
  • Contact Current AC Max: 16A
  • Contact Current Max: 30A
  • Contact Voltage AC Max: 250V
  • Contact Voltage AC Nom: 250V
  • Current Rating: 16A
  • External Depth: 58.4mm
  • External Height: 84mm
  • External Length / Height: 84mm
  • External Width: 17.4mm
  • Nom Operating Power: 5W
  • Operating Temperature Max: 40°C
  • Operating Temperature Min: -40°C
  • Relay Type: Power
  • Termination Type: Clamp
  • Type: Step
