DSP1A-DC24V Relay, SPST-NO, 250VAC, 30Vdc, 8A Panasonic

PANASONICSKU:DSP1A-DC24V Bestelcode:1448355

Prijs:
Actie prijs€8,63

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (842 units)

Documenten en downloads

Omschrijving

PANASONIC - DSP1A-DC24V - General Purpose Relay, DSP Series, Power, Non Latching, SPST-NO, 24 VDC, 8 A

  • Contact Configuration: SPST-NO
  • Coil Voltage: 24VDC
  • Contact Current: 8A
  • Product Range: DSP Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 30VDC
  • Contact Material: Silver Tin Oxide
  • Coil Resistance: 1.92kohm
  • SVHC: No SVHC (07-Jul-2017)
  • Approval Bodies: CSA, TUV
  • Approval Category: UL Recognised
  • Approvals & Standards: CSA, UL
  • Coil Current: 12.5mA
  • Coil Voltage VDC Nom: 24V
  • Contact Current AC Max: 8A
  • Contact Current DC Max: 8A
  • Contact Current Max: 8A
  • Contact Resistance: 30mohm
  • Contact Voltage AC Max: 250V
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Max: 30V
  • Contact Voltage DC Nom: 30V
  • DC Coil Power: 300mW
  • External Depth: 11mm
  • External Height: 10.5mm
  • External Length / Height: 10.5mm
  • External Width: 20.2mm
  • Nom Operating Power: 300mW
  • Operating Temperature Max: 65°C
  • Operating Temperature Min: -40°C
  • Operating Time: 10ms
  • Relay Type: Power - General Purpose
  • Release Time: 10ms
