EEUED2G220 Cap, 22µF, 400V, 20% Panasonic

PANASONICSKU:EEUED2G220 Bestelcode:9696482

Prijs:
Actie prijs€2,70

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (2414 units)

Documenten en downloads

Omschrijving

PANASONIC - EEUED2G220 - Electrolytic Capacitor, 22 µF, 400 V, ± 20%, Radial Leaded, 10000 hours @ 105°C, Polar

  • Capacitance: 22µF
  • Voltage Rating: 400V
  • Product Range: ED Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 12.5mm
  • Lead Spacing: 5mm
  • Height: 25mm
  • Operating Temperature Min: -25°C
  • Operating Temperature Max: 105°C
  • Lifetime @ Temperature: 10000 hours @ 105°C
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 25mm
  • Lead Diameter: 0.6mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -25°C to +105°C
  • Operating life Time: 10000h
  • Ripple Current AC: 500mA
  • Ripple Current Frequency: 100kHz
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 400V
