G2R-2-S- DC24 Relay, DPDT, 250VAC, 30Vdc, 5A Omron

OMRONSKU:G2R-2-S- DC24 Bestelcode:1448161

Prijs:
Actie prijs€13,36

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (10 units)

Documenten en downloads

Omschrijving

OMRON - G2R-2-S- DC24 - Power Relay, DPDT, 24 VDC, 5 A, G2RS, Socket, Non Latching

  • Contact Configuration: DPDT
  • Coil Voltage: 24VDC
  • Contact Current: 5A
  • Product Range: G2RS Series
  • Relay Mounting: Socket
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Quick Connect
  • Contact Voltage VDC: 30VDC
  • Contact Material: Silver Alloy
  • Coil Resistance: 1.1kohm
  • Approval Bodies: CSA, SEMKO, SEV, TUV, VDE
  • Approval Category: UL Recognised
  • Approvals & Standards: CE, CSA, IEC, UL, VDE
  • Coil Current: 21.8mA
  • Coil Voltage VDC Nom: 24V
  • Contact Current AC Max: 5A
  • Contact Current DC Max: 5A
  • Contact Current Max: 5A
  • Contact Current Min: 100mA
  • Contact Resistance: 100mohm
  • Contact Voltage AC Max: 250V
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Max: 30V
  • Contact Voltage DC Nom: 30V
  • DC Coil Power: 530mW
  • Dielectric Voltage Coil to Contact: 5000VAC
  • Dielectric Voltage Contact to Contact: 1000VAC
  • External Depth: 13mm
  • External Height: 28mm
  • External Length / Height: 28mm
  • External Width: 29mm
  • Insulation Resistance: 1000Mohm
  • Insulation Resistance Voltage: 500VDC
