OMI-SS-106LM,000 Relay, SPST, 250VAC, 30Vdc, 10A OEG - Te Connectivity

OEG - TE CONNECTIVITYSKU:OMI-SS-106LM,000 Bestelcode:1891762

Prijs:
Actie prijs€1,84

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (19 units)

Documenten en downloads

Omschrijving

  • Contact Configuration: SPST-NO
  • Coil Voltage: 6VDC
  • Contact Current: 10A
  • Product Range: OMI Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 30VDC
  • Contact Material: Silver Tin Oxide
  • Coil Resistance: 68ohm
  • SVHC: No SVHC (15-Jan-2018)
  • Approvals & Standards: CSA, UL, VDE
  • Coil Voltage VDC Nom: 6V
  • Contact Current Max: 10A
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Nom: 30V
  • External Depth: 29.2mm
  • External Height: 20.6mm
  • External Width: 12.8mm
  • Nom Operating Power: 540mW
  • Relay Type: Power
