V23092-A1024-A301 RELAY, SPDT, 250VAC, 6A SCHRACK - TE CONNECTIVITY

SCHRACK - TE CONNECTIVITYSKU:V23092-A1024-A301 Bestelcode:1175053

Prijs:
Actie prijs€15,74

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (2793 units)

Documenten en downloads

Omschrijving

SCHRACK - TE CONNECTIVITY - 2-1393236-4 - General Purpose Relay, SNR Series, Power, Non Latching, SPDT, 24 VDC, 6 A

  • Contact Configuration: SPDT
  • Coil Voltage: 24VDC
  • Contact Current: 6A
  • Product Range: SNR Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: -
  • Contact Material: Silver Tin Oxide
  • Coil Resistance: 3.39kohm
  • SVHC: No SVHC (15-Jan-2018)
  • Coil Voltage VDC Nom: 24V
  • Contact Current Max: 6A
  • Contact Voltage AC Nom: 250V
  • External Depth: 5mm
  • External Height: 15mm
  • External Width: 28mm
  • Nom Operating Power: 170mW
  • Relay Type: Power - General Purpose
