XKD10306 Relay, DIN Rail, 3a Celduc

CELDUCSKU:XKD10306 Bestelcode:3822590

Prijs:
Actie prijs€69,98

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (317 units)

Documenten en downloads

Omschrijving

CELDUC - XKD10306 - Solid State Relay, 3 A, 60 VDC, DIN Rail, Screw

  • Contact Configuration: -
  • Load Current: 3A
  • Operating Voltage Max: 60VDC
  • Relay Mounting: DIN Rail
  • Relay Terminals: Screw
  • Switching Mode: -
  • Operating Voltage Min: 2VDC
  • Control Voltage Min: 5VDC
  • Control Voltage Max: 30VDC
  • Product Range: -
  • SVHC: No SVHC (07-Jul-2017)
  • Control Voltage DC Max: 30VDC
  • Control Voltage DC Min: 5VDC
  • Control Voltage Range: 5V DC to 30V DC
  • Control Voltage Type: DC
  • Current Rating: 3A
  • External Width: 11.5mm
  • Input Voltage Max: 60VAC
  • Input Voltage Min: 24VAC
  • Load Current Min: 3mA
  • Load Current RMS Max: 3A
  • Operating Temperature Max: 80°C
  • Operating Temperature Min: -40°C
  • Operating Voltage Range: 2V DC to 60V DC
  • Output Type: Triac
  • Peak Surge Current: 5A
  • RMS Load Current Min: 3mA
