10.4310 Insert, Male, 4WAY Epic

EPICUGS :10.4310 Code de commande:9906282

Prix:
Prix ​​promotionnel€9,53

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (64 unité)

Documenten en downloads

description

EPIC - 10.4310 - Rectangular Power Connector, Insert, 4 Contacts, EPIC, Panel Mount, Screw, Plug

  • No. of Contacts: 4Contacts
  • Product Range: EPIC Series
  • Connector Mounting: Panel Mount
  • Contact Termination Type: Screw
  • Pitch Spacing: -
  • Gender: Plug
  • Contact Gender: -
  • Contact Material: Copper Alloy
  • Contact Plating: Silver Plated Contacts
  • Connector Shell Size: -
  • No. of Rows: 2Rows
  • SVHC: No SVHC (15-Jan-2019)
  • Approval Bodies: CSA, UL, VDE
  • Colour: Grey
  • Conduit Thread Size: PG11
  • Connector Type: Rectangular Power
  • Contact Termination: Screw
  • Current Rating: 10A
  • IP / NEMA Rating: IP65
  • Material: Thermoplastic Resin
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -40°C
  • Termination Method: Screw
  • Voltage Rating VAC: 400V
  • Wire Area Size Max: 2.5mm²
  • Wire Area Size Min: 0.5mm²
  • Working Voltage: 400V
