63RX3047M10X12.5 Cap, 47µF, 63V, 20% RUBYCON

RUBYCONUGS :63RX3047M10X12.5 Code de commande:8127220

Prix:
Prix ​​promotionnel€0,59

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (601 unité)

Documents et téléchargements

description

RUBYCON - 63RX3047M10X12.5 - Electrolytic Capacitor, Miniature, 47 µF, 63 V, ± 20%, Radial Leaded, 2000 hours @ 130°C, Polar

  • Capacitance: 47µF
  • Voltage Rating: 63V
  • Product Range: RX30 Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 10mm
  • Lead Spacing: 5mm
  • Height: 12.5mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 130°C
  • Lifetime @ Temperature: 2000 hours @ 130°C
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 12.5mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +130°C
  • Operating life Time: 4000h
  • Ripple Current AC: 400mA
  • Tolerance -: 20%
  • Voltage Rating V DC: 63V
