PANASONIC - EEVHD2A3R3P - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 3.3 µF, 100 V, 5000 hours @ 105°C, Polar
- AE Capacitor Case: Radial Can - SMD
- Capacitance: 3.3µF
- Voltage Rating: 100V
- ESR: -
- Product Range: -
- Lifetime @ Temperature: 5000 hours @ 105°C
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Ripple Current AC: 30mA
- Diameter: 8mm
- Height: 6.2mm
- Automotive Qualification Standard: -
- MSL: -
- SVHC: No SVHC (12-Jan-2017)
- Capacitance Tolerance: ± 20%
- Capacitance Tolerance ±: ± 20%
- Capacitor Case Style: Radial Can - SMD
- External Depth: 8.3mm
- External Length / Height: 6.2mm
- External Width: 8.3mm
- Lead Cross-section Width: 0.65mm
- Leakage Current: 3µA
- Operating Temperature Range: -40°C to +105°C
- Operating life Time: 5000h
- Power Factor: 0.18
- Power Factor Frequency: 120Hz
- Tape Width: 16mm
- Tolerance +: 20%
- Tolerance -: 20%
- Voltage Rating V DC: 100V
