CELDUC - SC841110 - Solid State Relay, 12 A, 280 Vrms, Panel Mount, Screw, Zero Crossing
- Contact Configuration: -
- Load Current: 12A
- Operating Voltage Max: 280Vrms
- Relay Mounting: Panel
- Relay Terminals: Screw
- Switching Mode: Zero Crossing
- Operating Voltage Min: 12Vrms
- Control Voltage Min: 4VDC
- Control Voltage Max: 30VDC
- Product Range: -
- SVHC: No SVHC (07-Jul-2017)
- Contact Voltage AC Max: 600V
- Control Voltage AC Max: 280VAC
- Control Voltage AC Min: 12VAC
- Control Voltage DC Max: 30VDC
- Control Voltage DC Min: 4VDC
- Control Voltage Range: 4V DC to 30V DC
- Control Voltage Type: DC
- External Depth: 27mm
- External Length / Height: 58.2mm
- External Width: 44.5mm
- Isolation Voltage: 4kV
- Load Current Min: 5mA
- Load Current RMS Max: 12A
- Operating Temperature Max: 100°C
- Operating Temperature Min: -40°C
- Operating Voltage Range: 12Vrms to 280Vrms
- Output Type: Triac
- RMS Load Current Min: 5mA
- RMS Load Voltage Max: 230V
- RMS Load Voltage Min: 12VAC
- Resistance: 1000ohm
- Resistance Temperature: 90°C
- Response Time Off Max: 10ms
- Response Time On Max: 10ms
- Surge Current: 120A
