SKKH57/16e Thyristor Module, 60A, 1600V SEMIKRON

SEMIKRONUGS :SKKH57/16E Code de commande:2301724

Prix:
Prix ​​promotionnel€44,52

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 2 produits disponibles

Documents et téléchargements

description

SEMIKRON - SKKH57/16E - Thyristor / Diode Module, Series Connected, 50 A, 1.6 kV

  • SCR Module Type: Series Connected - SCR / Diode
  • Peak Repetitive Off-State Voltage, Vdrm: 1.6kV
  • Gate Trigger Current Max, Igt: 150mA
  • Current It av: 50A
  • On State RMS Current IT(rms): 95A
  • Peak Non Rep Surge Current Itsm 50Hz: 1.5kA
  • Holding Current Max Ih: 250mA
  • Gate Trigger Voltage Max Vgt: 3V
  • Operating Temperature Max: 125°C
  • Product Range: -
  • SVHC: No SVHC (15-Jun-2015)
  • Current Itsm: 1500A
  • No. of Pins: 7Pins
  • Operating Temperature Min: -40°C
  • Repetitive Reverse Voltage Vrrm Max: 1600V
  • Thyristor Case Style: Module
