TMP 15124 Converter, AC/DC, 24V, 0.6a/15w, Module TRACO Power

TRACO POWERUGS :TMP 15124 Code de commande:1672143

Prix:
Prix ​​promotionnel€51,82

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (8 unité)

Documents et téléchargements

description

TRACO POWER - TMP 15124 - AC/DC PCB Mount Power Supply (PSU), ITE, 1 Output, 15 W, 24 V, 625 mA

  • No. of Outputs: 1 Output
  • Output Power Max: 15W
  • Output Voltage - Output 1: 24V
  • Output Current - Output 1: 625mA
  • Output Voltage - Output 2: -
  • Output Current - Output 2: -
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Power Supply Output Type: Fixed
  • Input Voltage VAC: 85V AC to 264V AC
  • Width: 54mm
  • Height: 19.3mm
  • Depth: 74mm
  • Product Range: TMP Series
  • SVHC: No SVHC (27-Jun-2018)
  • Applications: General Purpose
  • Approval Bodies: CB, EN, IEC, UL
  • Input Voltage AC Max: 264V
  • Input Voltage AC Min: 85V
  • Length: 74mm
  • No. of Outputs: 1Outputs
  • Output Current Max: 625mA
  • Power Rating: 15W
  • Power Supply Type: Enclosed
  • Supply Voltage Typ: 115V AC, 230V AC
