HARTING - 09641247232 - D Sub Connector, Right Angle, Filtered, Plug, 9 Contacts, DE, Solder
- Product Range: -
- D Sub Shell Size: DE
- Gender: Plug
- No. of Contacts: 9Contacts
- Capacitance: 1000pF
- Connector Body Material: Steel Body
- Contact Termination Type: Solder
- Contact Material: -
- Contact Plating: -
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: UL
- Case Material: Steel
- Connector Mounting: Through Hole Mount Right Angle
- Contact Resistance: 10mohm
- Contact Termination: Solder
- D Sub Connector Type: Filtered
- DC Current Max: 7.5A
- Flammability Rating: UL94V-0
- Insulation Resistance: 1000Mohm
- No. of Mating Cycles: 200
- Nominal Capacitance: 1000pF
- Operating Temperature Max: +125°C
- Operating Temperature Min: -55°C
- Thread Size: 4-40 UNC
- Withstand Voltage: 250V
- Working Voltage: 100V
