10136-6000EL Plug, MDR, Cable Mount, 36WAY 3M

3MSKU:10136-6000EL Bestelcode:9292691

Prijs:
Actie prijs€13,66

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (82 units)

Documenten en downloads

Omschrijving

3M - 10136-6000EL - D Sub Connector, Mini D (Ribbon Connector), Plug, MDR 101, 36 Contacts, IDC / IDT

  • No. of Contacts: 36Contacts
  • Gender: Plug
  • Product Range: MDR 101 Series
  • Contact Termination Type: IDC / IDT
  • Connector Mounting: Cable Mount
  • Contact Plating: Gold Plated Contacts
  • Contact Material: Beryllium Copper
  • SVHC: No SVHC (15-Jan-2018)
  • Connector Body Material: Steel Body
  • Connector Mounting Orientation: Cable
  • Connector Type: Micro D Ribbon
  • Contact Termination: IDC / IDT
  • Current Rating: 1A
  • D Sub Connector Type: Mini D (Ribbon Connector)
  • Flammability Rating: UL94V-0
  • Insulation Resistance: 500Mohm
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -20°C
  • Pitch Spacing: 1.27mm
  • Termination Method: IDC
  • Withstand Voltage: 500V
