19031352 LED INDICATOR, 24V, YELLOW CML INNOVATIVE TECHNOLOGIES

CML INNOVATIVE TECHNOLOGIES - 19031352 - LED Panel Mount Indicator, Black Chrome Bezel, Yellow, 24 VDC, 6 mm, 15 mA, 6 mcd, IP40

• LED Colour: Yellow
• Operating Voltage: 24VDC
• Mounting Hole Dia: 6mm
• Forward Current If: 15mA
• Luminous Intensity: 6mcd
• IP / NEMA Rating: IP40
• Product Range: -
• SVHC: No SVHC (15-Jan-2018)
• Approval Bodies: CE
• Bezel Diameter: 7mm
• Bulb Size: 3mm
• Current If Luminous Intensity: 18mA
• External Diameter: 7mm
• Fixing Hole Diameter: 6mm
• Forward Current If Max: 15mA
• Forward Voltage: 24V
• Forward Voltage VF Max: 24V
• LED / Lamp Size: 3mm
• Length Behind Bezel: 30.4mm
• Lens Shape: Round
• Luminous Intensity Typ: 25mcd
• Operating Temperature Max: 70°C
• Operating Temperature Min: -55°C
• Operating Temperature Range: -55°C to +70°C
• Operating Voltage Tolerance +: 10%
• Operating Voltage Tolerance -: 10%
• PIV Max: 5V
• Peak Forward Current: 18mA
• Peak Wavelength: 590nm
• Supply Voltage: 24V
• Supply Voltage V DC: 24V
• Thread Pitch: 0.75mm
• Thread Size: M6
• Voltage Rating V DC: 24V
• Voltage Vf Typ: 24V
• Wavelength Typ: 590nm
