RUBYCON - 35ZLH560MEFC10X20 - Electrolytic Capacitor, Miniature, 560 µF, 35 V, ± 20%, Radial Leaded, 10000 hours @ 105°C, Polar
- Capacitance: 560µF
- Voltage Rating: 35V
- Product Range: ZLH Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 10mm
- Lead Spacing: 5mm
- Height: 20mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 10000 hours @ 105°C
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 20mm
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +105°C
- Operating life Time: 10000h
- Ripple Current AC: 1960mA
- Tolerance -: 20%
- Voltage Rating V DC: 35V
