AR50KL.25 Potentiometer, 50k 5W TT Electronics / Bi Technologies

TT ELECTRONICS / BI TECHNOLOGIESSKU:AR50KL.25 Bestelcode:9431888

Prijs:
Actie prijs€336,96

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Uitverkocht

Documenten en downloads

Omschrijving

TT ELECTRONICS / BI TECHNOLOGIES - AR50KL.25 - Rotary Potentiometer, Wirewound, 50 kohm, 10 Turns, Linear, 5 W, ± 1%, A

  • Track Resistance: 50kohm
  • No. of Turns: 10Turns
  • Track Taper: Linear
  • Power Rating: 5W
  • Resistance Tolerance: ± 1%
  • Product Range: A Series
  • Potentiometer Mounting: Panel
  • Shaft Diameter: 6.34mm
  • No. of Gangs: 1
  • Adjustment Type: Screwdriver Slot
  • Shaft Length: 20.6mm
  • SVHC: No SVHC (20-Jun-2016)
  • Body Diameter: 46.03mm
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -65°C
  • Operating Temperature Range: -65°C to +85°C
  • Resistor Element Material: Wirewound
  • Temperature Coefficient: ± 130ppm/°C
  • Termination Type: Solder
  • Voltage Rating: 1kV
