CAMDENBOSS - CTB9350/8AO - Terminal Block, Header, Plug, 5 mm, 8 Ways, 20 A, 320 V
- Pitch Spacing: 5mm
- No. of Positions: 8Ways
- Wire Size (AWG): 30AWG to 12AWG
- Conductor Area CSA: 2.5mm²
- Wire Connection Method: Screw
- Rated Current: 20A
- Rated Voltage: 320V
- Product Range: CTB9350/AO Series
- SVHC: No SVHC (15-Jan-2019)
- Colour: Green
- Contact Material: Brass
- Contact Plating: Copper Plated Contacts
- Contact Termination: Through Hole Right Angle
- Contact Termination Type: Through Hole
- Current Rating: 12A
- Flammability Rating: UL94V-0
- Gender: Plug
- Lead Spacing: 5mm
- No. of Contacts: 8Contacts
- No. of Rows: 1Rows
- Operating Temperature Max: 125°C
- Operating Temperature Min: -20°C
- Termination Method: Solder
- Thread Size: M3
- Voltage Rating VAC: 380V
- Wire Size AWG Max: 12AWG
- Wire Size AWG Min: 30AWG
