CAMDENBOSS - CTB9508/8 - Terminal Block, Header, 7.62 mm, 8 Ways, 12 A, 500 V, Through Hole Vertical
- Gender: Header
- Pitch Spacing: 7.62mm
- No. of Positions: 8Ways
- Rated Current: 12A
- Rated Voltage: 500V
- Block Orientation: Through Hole Vertical
- Product Range: CTB9508 Series
- SVHC: No SVHC (15-Jan-2019)
- Cable Diameter Max: 2.5mm
- Colour: Green
- Connector Mounting: Cable Mount
- Connector Type: Terminal Block, Pluggable
- Contact Material: Phosphor Bronze
- Contact Plating: Tin Plated Contacts
- Insulation Resistance: 5Mohm
- Length: 60.96mm
- Material: UL94-V0 Flame Retardant PA66
- Operating Temperature Max: 125°C
- Operating Temperature Min: -20°C
- Wire Size AWG Max: 12AWG
- Wire Size AWG Min: 30AWG
- Withstand Voltage: 2.5kV
- Working Voltage: 380V
