CTSN431/12/F Terminal Block, Pluggable, 12Pos Camdenboss

CAMDENBOSSSKU:CTSN431/12/F Bestelcode:7875061

Prijs:
Actie prijs€9,01

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (921 units)

Documenten en downloads

Omschrijving

CAMDENBOSS - CTSN431/12/F - Panel Mount Barrier Terminal Block, 1 Row, 12 Ways, 8 mm, 17.5 A

  • No. of Rows: 1 Row
  • No. of Positions: 12Ways
  • Wire Size AWG Min: -
  • Wire Size AWG Max: -
  • Pitch Spacing: 8mm
  • Rated Current: 17.5A
  • Rated Voltage: 450V
  • Product Range: CTSN431 Series
  • SVHC: No SVHC (15-Jan-2019)
  • Approval Bodies: CE, IMQ
  • Connector Mounting: Cable Mount
  • Connector Type: Terminal Block, Pluggable
  • Contact Material: Brass
  • Contact Plating: Nickel Plated Contacts
  • External Length / Height: 15.3mm
  • External Width: 16mm
  • Fixing Hole Diameter: 2.5mm
  • Flammability Rating: UL94V-2
  • Material: Self extinguishing Polypropylene
  • No. of Rows: 1Rows
  • Operating Temperature Max: 110°C
  • Suitable Screw: M3
  • Voltage Rating AC Max: 450VAC
  • Wire Connection Method: Screw
