DSP100-15 PSU, DIN Rail, 15V, 5A, 75W TDK-Lambda

TDK-LAMBDASKU:DSP100-15 Bestelcode:1456487

Prijs:
Actie prijs€95,00

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (5 units)

Documenten en downloads

Omschrijving

TDK-LAMBDA - DSP100-15 - AC/DC DIN Rail Power Supply (PSU), ITE, 1 Output, 75 W, 15 VDC, 5 A

  • No. of Outputs: 1 Output
  • Output Power Max: 75W
  • Output Voltage - Output 1: 15VDC
  • Output Current - Output 1: 5A
  • Output Voltage - Output 2: -
  • Output Current - Output 2: -
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Output Voltage - Output 4: -
  • Current, Output 4: -
  • Input Voltage VAC: 90V AC to 264V AC
  • Power Supply Output Type: Adjustable, Fixed
  • Product Range: DSP Series
  • SVHC: No SVHC (15-Jan-2018)
  • Applications: Industrial
  • Approval Bodies: CE, EN, UL
  • Efficiency: 85%
  • External Depth: 56.8mm
  • External Length / Height: 91mm
  • External Width: 90mm
  • Height: 91mm
  • Input Frequency: 63Hz
  • Input Voltage AC Max: 264VAC
  • Input Voltage AC Min: 90VAC
  • Inrush Current: 60A
  • Length: 56.8mm
  • Line Regulation: 1%
  • Load Regulation: 1%
  • No. of Outputs: 1Outputs
  • Operating Temperature Max: 71°C
  • Operating Temperature Min: -25°C
  • Output Current: 5A
  • Output Ripple Voltage pk-pk: 50mV
  • Output Voltage: 15V
  • Output Voltage Max: 16.5V
  • Output Voltage Min: 13.5V
  • Output Voltage Nom.: 15V
  • Power Rating: 75W
