SENSATA/CRYDOM - EZ240D12 - Solid State Relay, SPST-NO, 12 A, 280 Vrms, Panel Mount, Quick Connect, Zero Crossing
- Contact Configuration: SPST-NO
- Load Current: 12A
- Operating Voltage Max: 280Vrms
- Relay Mounting: Panel
- Relay Terminals: Quick Connect
- Switching Mode: Zero Crossing
- Operating Voltage Min: 24Vrms
- Control Voltage Min: 3VDC
- Control Voltage Max: 15VDC
- Product Range: EZ Series
- SVHC: No SVHC (12-Jan-2017)
- Blocking voltage: 600V
- Control Current Typ: 15mA
- Control Voltage DC Max: 15VDC
- Control Voltage DC Min: 3VDC
- Control Voltage Range: 3V DC to 15V DC
- Control Voltage Type: DC
- External Depth: 24.1mm
- External Length / Height: 66.8mm
- External Width: 38mm
- Input Impedance: 300ohm
- Isolation Voltage: 4kV
- Load Current Min: 150mA
- Load Current RMS Max: 12A
- Operating Voltage Range: 24Vrms to 280Vrms
- Output Type: SCR
- RMS Load Current Min: 150mA
- RMS Load Voltage Max: 280V
- RMS Load Voltage Min: 24V
- Rate of Voltage Change dv / dt: 500V/µs
- Single Cycle Surge Current: 150A
- Surge Current: 150A
