EZ240D5 SSR SENSATA/Crydom

SENSATA/CRYDOMSKU:EZ240D5 Bestelcode:1200289

Prijs:
Actie prijs€38,54

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (148 units)

Documenten en downloads

Omschrijving

SENSATA/CRYDOM - EZ240D5 - Solid State Relay, 5 A, 280 Vrms, Panel Mount, Quick Connect

  • Contact Configuration: -
  • Load Current: 5A
  • Operating Voltage Max: 280Vrms
  • Relay Mounting: Panel
  • Relay Terminals: Quick Connect
  • Switching Mode: -
  • Operating Voltage Min: 24Vrms
  • Control Voltage Min: 4VDC
  • Control Voltage Max: 15VDC
  • Product Range: EZ Series
  • SVHC: No SVHC (12-Jan-2017)
  • Blocking voltage: 600V
  • Control Current Typ: 13mA
  • Control Voltage DC Max: 15VDC
  • Control Voltage DC Min: 4VDC
  • Control Voltage Range: 4V DC to 15V DC
  • Control Voltage Type: DC
  • External Depth: 24.1mm
  • External Length / Height: 66.8mm
  • External Width: 38mm
  • Input Impedance: 300ohm
  • Isolation Voltage: 4kV
  • Load Current Min: 150mA
  • Load Current RMS Max: 5A
  • Operating Voltage Range: 24Vrms to 280Vrms
  • Output Type: SCR
  • RMS Load Current Min: 150mA
  • RMS Load Voltage Max: 280V
  • RMS Load Voltage Min: 24V
  • Rate of Voltage Change dv / dt: 500V/µs
  • Single Cycle Surge Current: 85A
  • Surge Current: 40A
