FN2090-6-06 Filter, 1 PH, 6a, Chassis Mount Schaffner

SCHAFFNERSKU:FN2090-6-06 Bestelcode:1304858

Prijs:
Actie prijs€33,81

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (13 units)

Documenten en downloads

Omschrijving

SCHAFFNER - FN2090-6-06 - Power Line Filter, Chassis, General Purpose, 250 VAC, 6 A, Single Phase, 2 Stage, Chassis Mount

  • Current Rating: 6A
  • Voltage Rating: 250VAC
  • Filter Type: EMI, RFI
  • Filter Terminals: Quick Connect
  • Inductance Min: 8mH
  • Capacitance: 0.47µF
  • Leakage Current Max: 0.67µA
  • Product Range: -
  • SVHC: No SVHC (15-Jan-2019)
  • Bleed Resistor Resistance: 330kohm
  • External Depth: 30.3mm
  • External Length / Height: 85mm
  • External Width: 54mm
  • Inductance: 8µH
  • Leakage Current: 0.67µA
  • No. of Phases: Single Phase
  • Operating Temperature Max: 100°C
  • Operating Temperature Min: -25°C
  • Voltage Rating VAC: 250V
