GBU6K-e3/51 Bridge Rectifier, 6a, 800V Vishay

VISHAYSKU:GBU6K-E3/51 Bestelcode:9549510

Prijs:
Actie prijs€3,87

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (1092 units)

Documenten en downloads

Omschrijving

VISHAY - GBU6K-E3/51 - Bridge Rectifier, Single Phase, 800 V, 6 A, SIP, 4 Pins, 1 V

  • No. of Phases: Single Phase
  • Repetitive Reverse Voltage Vrrm Max: 800V
  • Forward Current If(AV): 6A
  • Bridge Rectifier Case Style: SIP
  • Forward Voltage VF Max: 1V
  • No. of Pins: 4Pins
  • Operating Temperature Max: 150°C
  • Product Range: GBU6K Series
  • SVHC: Lead (15-Jan-2019)
  • Ambient Temperature Ta: 40°C
  • Body Height Max: 18.8mm
  • Device Marking: GBU6K
  • Diode Configuration: Dual Independent
  • Diode Mounting Type: Through Hole
  • Diode Type: Bridge Rectifier
  • External Depth: 3.56mm
  • External Length / Height: 18.8mm
  • External Width: 22.3mm
  • Flammability Rating: UL
  • Forward Surge Current Ifsm Max: 175A
  • Lead Spacing: 5.1mm
  • Operating Temperature Min: -55°C
  • Operating Temperature Range: -55°C to +150°C
  • Output Current Max: 6A
  • RMS Input Voltage: 560V
