Omschrijving
BROADCOM - HEDS-9140#I00 - Rotary Encoder, Optical, Incremental, 512 PPR, 0 Detents, Vertical, Without Push Switch
- Supply Voltage Min: 4.5V
- Supply Voltage Max: 5.5V
- No. of Channels: 3 Channel
- Rotational Speed Max: 30000rpm
- Encoder Resolution: 512CPR
- Product Range: HEDS-9140 Series
- SVHC: No SVHC (15-Jan-2018)
- External Depth: 11.7mm
- External Length / Height: 10.16mm
- External Width: 26.67mm
- Frequency Max: 100kHz
- No. of Channels: 3Channels
- Operating Temperature Max: 100°C
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +100°C
- Rotational Speed: 30000rpm
- Sensor Supply Voltage: 4.5V DC to 5.5V DC
- Slot Width: 1.78mm
- Supply Voltage: 5V
- Supply Voltage Range: 4.5V to 5.5V
- Type: Optical Incremental Encoder
