PX0727/P Plug, Sealed Panel, 9WAY Bulgin Limited

BULGIN LIMITEDSKU:PX0727/P Bestelcode:469701

Prijs:
Actie prijs€33,40

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (6 units)

Documenten en downloads

Omschrijving

BULGIN LIMITED - PX0727/P - Circular Connector, Buccaneer Standard Series, Panel Mount Plug, 9 Contacts, Crimp Pin, Threaded

  • Product Range: Buccaneer Standard Series
  • Circular Connector Shell Style: Panel Mount Plug
  • No. of Contacts: 9Contacts
  • Circular Contact Type: Crimp Pin
  • Coupling Style: Threaded
  • Connector Body Material: Nylon (Polyamide), Glass Filled Body
  • Connector Body Plating: -
  • Contact Material: Copper Alloy
  • Contact Plating: Tin
  • SVHC: No SVHC (27-Jun-2018)
  • Cable Diameter Max: 8.1mm
  • Colour: Black
  • Connector Mounting: Panel Mount
  • Connector Type: Circular Industrial
  • Contact Gender: Pin
  • Contact Plating: Tin Plated Contacts
  • Contact Resistance Max: 10mohm
  • Contact Termination: Crimp
  • Contact Termination Type: Crimp
  • Current Rating: 5A
  • External Diameter: 37.1mm
  • External Length / Height: 32mm
  • Flammability Rating: UL94V-0
  • Gender: Plug
  • IP / NEMA Rating: IP68
  • Insulation Resistance: 100Mohm
  • Moulding Material: Glass Filled Nylon
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -20°C
  • Panel Thickness Max: 6.4mm
  • Panel Thickness Min: 0.8mm
  • Voltage Rating V DC: 150V
  • Voltage Rating VAC: 150V
