SKA20420 SSR, 4A, 275VAC CELDUC

CELDUCSKU:SKA20420 Bestelcode:1214568

Prijs:
Actie prijs€40,28

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (358 units)

Documenten en downloads

Omschrijving

CELDUC - SKA20420 - Solid State Relay, 4 A, 275 Vrms, PCB, Through Hole, Zero Crossing

  • Contact Configuration: -
  • Load Current: 4A
  • Operating Voltage Max: 275Vrms
  • Relay Mounting: PCB
  • Relay Terminals: Through Hole
  • Switching Mode: Zero Crossing
  • Operating Voltage Min: 12Vrms
  • Control Voltage Min: 4VDC
  • Control Voltage Max: 30VDC
  • Product Range: -
  • SVHC: No SVHC (07-Jul-2017)
  • Control Voltage DC Max: 30VDC
  • Control Voltage DC Min: 4VDC
  • Control Voltage Range: 4V DC to 30V DC
  • Control Voltage Type: DC
  • External Depth: 10.2mm
  • External Length / Height: 43.2mm
  • External Width: 25.4mm
  • Height: 43.2mm
  • I2t: 50s
  • Input Voltage: 4V DC to 30V DC
  • Insulation Resistance: 1kohm
  • Isolation Voltage: 4kV
  • Load Current Min: 5mA
  • Load Current RMS Max: 4A
  • Load Voltage Range: 12V AC to 275V AC
  • Operating Current DC: 3mA
  • Operating Frequency: 440Hz
  • Operating Temperature Max: 80°C
  • Operating Temperature Min: -40°C
  • Operating Voltage Range: 12Vrms to 275Vrms
  • RMS Load Current Min: 5mA
  • RMS Load Voltage Max: 275VAC
  • RMS Load Voltage Min: 12VAC
  • Turn Off Time: 10ms
  • Turn On Time: 10ms
