TRACO POWER - TEL 3-2012 - Isolated Through Hole DC/DC Converter, ITE, 3:1, 3 W, 1 Output, 12 V, 250 mA
- No. of Outputs: 1 Output
- Output Power Max: 3W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 250mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: TEL 3 Series
- Input Voltage DC Min: 10V
- Input Voltage DC Max: 30V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 20mm
- Height: 10.2mm
- Depth: 32mm
- SVHC: No SVHC (27-Jun-2018)
- Approval Bodies: CSA, EN, IEC, UL
- Approvals & Standards: CSA, IEC, UL
- Efficiency: 78%
- External Depth: 20mm
- External Length / Height: 10mm
- External Width: 32mm
- Isolation Voltage: 1.5kV
- Line Regulation: 0.5%
- Load Regulation: 1%
- No. of Outputs: 1Outputs
- Output Ripple Voltage pk-pk: 60mV
- Power Rating: 3W
- Supply Voltage: 20V
