10TZV470M8X10.5 Cap, 470µF, 10V, Radial, SMD RUBYCON

RUBYCONUGS :10TZV470M8X10.5 Code de commande:1281858

Prix:
Prix ​​promotionnel€1,07

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (1865 unité)

Documents et téléchargements

description

RUBYCON - 10TZV470M8X10.5 - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 470 µF, 10 V, 2000 hours @ 105°C, Polar

  • AE Capacitor Case: Radial Can - SMD
  • Capacitance: 470µF
  • Voltage Rating: 10V
  • ESR: -
  • Product Range: TZV Series
  • Lifetime @ Temperature: 2000 hours @ 105°C
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 105°C
  • Ripple Current AC: 600mA
  • Diameter: 8mm
  • Height: 10.5mm
  • Automotive Qualification Standard: -
  • MSL: -
  • SVHC: No SVHC (15-Jan-2018)
  • Capacitance Tolerance: ± 20%
  • Capacitance Tolerance ±: ± 20%
  • Capacitor Case Style: Radial Can - SMD
  • External Length / Height: 10.5mm
  • Frequency Tolerance: 120Hz
  • Impedance: 0.16ohm
  • Impedance Frequency: 100kHz
  • Impedance Temperature: 20°C
  • Operating Temperature Range: -55°C to +105°C
  • Operating life Time: 2000h
  • Ripple Current Frequency: 100kHz
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Tolerance Temperature: 20°C
  • Voltage Rating V DC: 10V
  • Voltage Rating VAC: 10V
