1658527-4 Receptacle, S/Relief, IDC, 2.54mm, 10WAY Amp - Te Connectivity

AMP - TE CONNECTIVITYUGS :1658527-4 Code de commande:1298776

Prix:
Prix ​​promotionnel€4,92

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (4924 unité)

Documents et téléchargements

description

AMP - TE CONNECTIVITY - 1658527-4 - IDC Connector, With Strain Relief, IDC Receptacle, Female, 2.54 mm, 2 Row, 10 Contacts, Cable Mount

  • Pitch Spacing: 2.54mm
  • No. of Contacts: 10Contacts
  • Gender: Receptacle
  • Product Range: 622 Series
  • Contact Termination Type: IDC / IDT
  • No. of Rows: 2Rows
  • Contact Plating: Gold Plated Contacts
  • Contact Material: Beryllium Copper
  • SVHC: No SVHC (27-Jun-2018)
  • Contact Current Rating: 1A
  • Flammability Rating: UL94V-0
  • IDC Cable Pitch: 0.05"
  • Insulation Resistance: 1Gohm
  • Insulator Material: Thermoplastic, Glass Filled
  • No. of Mating Cycles: 400
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -55°C
  • Polarisation Type: Bump/Clip
  • Row Pitch: 2.54mm
  • Withstand Voltage: 1000V
