22.34.0.012.4720 Relay, 3PST-NO, SPST-NC, 250VAC, 25A Finder

FINDER - 22.34.0.012.4720 - Contactor, DIN Rail, 250 VAC, 3PST-NO, SPST-NC, 4 Pole, 4 kW

• Load Current Inductive: -
• Relay Mounting: DIN Rail
• Operating Voltage: 250VAC
• Contact Configuration: 3PST-NO, SPST-NC
• No. of Poles: 4 Pole
• Switching Power AC3: 4kW
• Switching Current AC1: -
• Coil Voltage VAC Nom: 12V
• Coil Voltage VDC Nom: 12V
• Switching Power AC1: -
• Load Current Resistive: 25A
• Switching Current AC3: 10A
• Product Range: 22 Series
• SVHC: No SVHC (15-Jan-2019)
• Approvals & Standards: CE
• Coil Voltage: 12V
• Contact Current: 25A
• Contact Current Max: 25A
• Contact Material: Silver Nickel
• Contact Voltage AC Nom: 250V
• Contact Voltage VAC: 250V
• External Depth: 60.8mm
• External Height: 84mm
• External Width: 35mm
• Nom Operating Power: 2VA
• Operating Temperature Max: 50°C
• Operating Temperature Min: -20°C
• Relay Terminals: Screw
• Relay Type: Modular
• Termination Type: Screw
