240D45-17 SSR, 45A, 240Vac Opto 22

OPTO 22UGS :240D45-17 Code de commande:7229021

Prix:
Prix ​​promotionnel€108,92

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (37 unité)

Documents et téléchargements

description

OPTO 22 - 240D45-17 - Solid State Relay, 45 A, 280 VAC, Panel Mount, Screw, DC Switch

  • Contact Configuration: -
  • Load Current: 45A
  • Operating Voltage Max: 280VAC
  • Relay Mounting: Panel
  • Relay Terminals: Screw
  • Switching Mode: DC Switch
  • Operating Voltage Min: 24VAC
  • Control Voltage Min: 3VDC
  • Control Voltage Max: 32VDC
  • Product Range: DC Series
  • SVHC: No SVHC (27-Jun-2018)
  • Control Voltage DC Max: 32VDC
  • Control Voltage DC Min: 3VDC
  • Control Voltage Range: 3V DC to 32V DC
  • Control Voltage Type: DC
  • I2t: 1750s
  • Isolation Voltage: 4kV
  • Leakage Current: 14mA
  • Load Current RMS Max: 45A
  • Operating Current DC: 45A
  • Operating Temperature Max: 100°C
  • Operating Temperature Min: -40°C
  • Operating Voltage Range: 24V AC to 280V AC
  • Output Type: SCR
  • RMS Load Voltage Max: 280V
  • RMS Load Voltage Min: 24V
  • Single Cycle Surge Current: 650A
