268003C Cable, 1Pair, 7/0.2mm, Red, 100m VAN Damme

VAN DAMMEUGS :268003C Code de commande:1891058

Prix:
Prix ​​promotionnel€131,90

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 4 produits disponibles

Documents et téléchargements

description

VAN DAMME - 268003C - Multicore Cable, Pro Grade Flex, Screened, 2 Core, 24 AWG, 0.22 mm², 328 ft, 100 m

  • Cable Shielding: Screened
  • No. of Cores: 2Core
  • Wire Gauge: 24AWG
  • Conductor Area CSA: 0.22mm²
  • Reel Length (Imperial): 328ft
  • Reel Length (Metric): 100m
  • Jacket Colour: Red
  • No. of Max Strands x Strand Size: 7 x 0.2mm
  • Conductor Material: Copper
  • Jacket Material: PVC
  • External Diameter: 3.5mm
  • Voltage Rating: -
  • Product Range: -
  • SVHC: No SVHC (27-Jun-2018)
  • Cable Type: Shielded
  • Core - Core Capacitance: 90pF/m
  • Core-Screen Capacitance: 189pF/m
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -25°C
  • Resistance per Metre: 0.078ohm
