VAN DAMME - 268401C - Multipair Cable, Audio, Screened, 1 Pair, 26 AWG, 0.14 mm², 328 ft, 100 m
- Cable Shielding: Screened
- No. of Pairs: 1 Pair
- Wire Gauge: 26AWG
- Conductor Area CSA: 0.14mm²
- Reel Length (Imperial): 328ft
- Reel Length (Metric): 100m
- Jacket Colour: Green
- No. of Max Strands x Strand Size: 7 x 0.16mm
- Voltage Rating: -
- Jacket Material: PVC
- Conductor Material: Copper
- External Diameter: 3.9mm
- Product Range: -
- SVHC: No SVHC (27-Jun-2018)
- Attenuation @ 10MHz: 7.241dB
- Attenuation @ 16MHz: 8.838dB
- Attenuation @ 1MHz: 2.156dB
- Attenuation @ 20MHz: 10.236dB
- Attenuation @ 4MHz: 4.347dB
- Core - Core Capacitance: 38pF/m
- Core-Screen Capacitance: 78pF/m
- Drain Wire Type: 7 x 0.16mm
- Impedance: 110ohm
- Operating Temperature Max: 70°C
- Operating Temperature Min: -20°C
- Screen Type Primary: Aluminium Polyester
- Voltage Rating VAC: 250V
