SCHRACK - TE CONNECTIVITY - 3-1415073-1... - Power Relay, DPDT, 230 VAC, 8 A, RT Package, DIN Rail, Non Latching
- Contact Configuration: DPDT
- Coil Voltage: 230VAC
- Contact Current: 8A
- Product Range: RT Package Series
- Relay Mounting: DIN Rail
- Coil Type: Non Latching
- Contact Voltage VAC: 240VAC
- Relay Terminals: Screw
- Contact Voltage VDC: -
- Contact Material: Silver Nickel
- Coil Resistance: 32.5kohm
- Coil Voltage VAC Nom: 230V
- Contact Current AC Max: 8A
- Contact Current Max: 8A
- Contact Voltage AC Max: 240V
- Contact Voltage AC Nom: 240V
- Current Rating: 8A
- External Depth: 69mm
- External Height: 77mm
- External Length / Height: 77mm
- External Width: 15.5mm
- Nom Operating Power: 0.74VA
- Operating Temperature Max: 70°C
- Operating Temperature Min: -40°C
- Relay Type: Power
