METZ CONNECT - 31271110 - Wire-To-Board Terminal Block, 5 mm, 10 Ways, 26 AWG, 14 AWG, 4 mm², Screw
- Pitch Spacing: 5mm
- No. of Positions: 10Ways
- Wire Size AWG Min: 26AWG
- Wire Size AWG Max: 14AWG
- Conductor Area CSA: 4mm²
- Wire Connection Method: Screw
- Rated Current: 15A
- Rated Voltage: 300V
- Block Orientation: Through Hole Right Angle
- Product Range: -
- SVHC: No SVHC (07-Jul-2017)
