3214W-1-102e Trimmer, SMD, 5 Turn 1K Bourns

BOURNSUGS :3214W-1-102E Code de commande:988248

Prix:
Prix ​​promotionnel€5,17

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (1383 unité)

Documents et téléchargements

description

BOURNS - 3214W-1-102E - Trimpot, Multi Turn, Cermet, Top Adjust, 1 kohm, Surface Mount, 5 Turns

  • Track Resistance: 1kohm
  • No. of Turns: 5Turns
  • Potentiometer Mounting: Surface Mount Device
  • Product Range: Trimpot 3214 Series
  • Power Rating: 250mW
  • Resistance Tolerance: ± 10%
  • Temperature Coefficient: ± 100ppm/°C
  • Automotive Qualification Standard: AEC-Q200
  • MSL: -
  • SVHC: No SVHC (15-Jan-2019)
  • Adjustment Type: Screwdriver Slot
  • Contact Resistance Variation +: 3%
  • End Resistance: 10ohm
  • External Depth: 3.9mm
  • External Length / Height: 5.1mm
  • External Width: 4.8mm
  • Operating Temperature Max: 150°C
  • Operating Temperature Min: -65°C
  • Operating Temperature Range: -65°C to +150°C
  • Proof Voltage: 600V
  • Reel Quantity: 250
  • Resistance: 1kohm
  • Resistor Element Material: Cermet
  • Resistor Mounting: Surface Mount Device
  • Tape Width: 16mm
  • Temperature Coeff. +: 100ppm/°C
  • Temperature Coeff. -: 100ppm/°C
  • Tolerance +: 10%
  • Tolerance -: 10%
  • Track Taper: Linear
  • Voltage Rating: 300V
  • Voltage Rating V DC: 300V
