3224W-1-201E Potentiometer, 200 OHM 0.25W Bourns

BOURNSUGS :3224W-1-201E Code de commande:1463554

Prix:
Prix ​​promotionnel€6,70

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (1590 unité)

Documents et téléchargements

description

BOURNS - 3224W-1-201E - Trimpot, Multi Turn, Cermet, Top Adjust, 200 ohm, Surface Mount, 12 Turns

  • Track Resistance: 200ohm
  • No. of Turns: 12Turns
  • Potentiometer Mounting: Surface Mount Device
  • Product Range: Trimpot 3224 Series
  • Power Rating: 250mW
  • Resistance Tolerance: ± 10%
  • Temperature Coefficient: ± 100ppm/°C
  • Automotive Qualification Standard: AEC-Q200
  • MSL: -
  • SVHC: No SVHC (15-Jan-2019)
  • Adjustment Type: Screwdriver Slot
  • Operating Temperature Max: 150°C
  • Operating Temperature Min: -65°C
  • Operating Temperature Range: -65°C to +150°C
  • Resistor Element Material: Cermet
  • Track Taper: Linear
  • Voltage Rating: 300V
