FINDER - 34.51.7.012.0019 - General Purpose Relay, 34 Series, SPDT, 12 VDC, 6 A
- Contact Configuration: SPDT
- Coil Voltage: 12VDC
- Contact Current: 6A
- Product Range: 34 Series
- Relay Mounting: Through Hole
- Coil Type: -
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: -
- Contact Material: Silver Nickel
- Coil Resistance: 840ohm
- SVHC: No SVHC (15-Jan-2019)
- Coil Current: 14.2mA
- Coil Voltage VDC Nom: 12V
- Contact Current Max: 10A
- Contact Voltage AC Nom: 250V
- External Depth: 28mm
- External Height: 15mm
- External Width: 5mm
- Nom Operating Power: 170mW
