FINDER - 38.51.0.048.0060 - General Purpose Relay, 38 Series, Interface, SPDT, 48 V, 6 A
- Contact Configuration: SPDT
- Coil Voltage: 48V
- Contact Current: 6A
- Product Range: 38 Series
- Relay Mounting: DIN Rail
- Coil Type: AC / DC
- Contact Voltage VAC: 250VAC
- Relay Terminals: Screw
- Contact Voltage VDC: 30V
- Contact Material: Silver Nickel
- Coil Resistance: -
- SVHC: No SVHC (15-Jan-2019)
- Approval Bodies: BEAB, CSA, DEMKO, IMQ, SEMKO, SETI, SEV, UL, VDE
- Approvals & Standards: CE, CSA, UL
- Average Power Consumption: 300mW
- Coil Voltage VAC Nom: 48V
- Coil Voltage VDC Nom: 48V
- Contact Current AC Max: 6A
- Contact Current Max: 10A
- Contact Voltage AC Max: 250V
- Contact Voltage AC Nom: 250V
- Current Rating: 6A
- Dielectric Strength VDC: 1000VAC
- External Depth: 75.6mm
- External Height: 87.3mm
- External Length / Height: 87.3mm
- External Width: 6.2mm
- IP / NEMA Rating: IP20
- Mechanical Life: 10,000,000 Operations
- No. of Mechanical Operations: 10000000
- Operating Temperature Max: 55°C
- Operating Temperature Min: -40°C
- Operating Time: 7ms
- Relay Type: Interface
- Release Time: 11ms
