FINDER - 39.80.0.024.9024 - Time Delay Relay, 24 VDC, 0.1 s, 6 h, 39 Series, SPST-NO, 2 A
- Contact Voltage VDC: 24VDC
- Time Min: 0.1s
- Time Max: 6h
- Product Range: 39 Series
- Contact Configuration: SPST-NO
- Contact Current: 2A
- Relay Mounting: DIN Rail
- Contact Voltage VAC: -
- Relay Terminals: Screw
- Nom Input Voltage: 24V
- Timing Adjustment: DIP Switch
- SVHC: No SVHC (15-Jan-2019)
- Delay Time Range: 0.1s to 3s, 3s to 60s, 1min to 20min, 0.3h to 6h
- Input Current Max: 19mA
- Input Current Min: 11mA
- Nom Voltage: 24V
