MOLEX - 39970-0103 - Wire-To-Board Terminal Block, 10.16 mm, 3 Ways, 18 AWG, 6 AWG, 10 mm², Screw
- Pitch Spacing: 10.16mm
- No. of Positions: 3Ways
- Wire Size AWG Min: 18AWG
- Wire Size AWG Max: 6AWG
- Conductor Area CSA: 10mm²
- Wire Connection Method: Screw
- Rated Current: 60A
- Rated Voltage: 300V
- Block Orientation: Through Hole Right Angle
- Product Range: Eurostyle 39970 Series
- SVHC: No SVHC (07-Jul-2017)
- Colour: Black
- Connector Mounting: PCB Mount
- Connector Type: Terminal Block, Eurostyle
- Contact Material: Brass
- Contact Plating: Nickel Plated Contacts
- Flammability Rating: UL94V-0
- Insulation Resistance: 5000Mohm
- Operating Temperature Max: 130°C
- Operating Temperature Min: -40°C
- Voltage Rating VAC: 300V
- Wire Area Size Max: 13.3mm²
- Working Voltage: 300V
