4114NHH FAN, 119MM, 24VDC EBM-PAPST

EBM-PAPSTUGS :4114NHH Code de commande:1293493

Prix:
Prix ​​promotionnel€150,91

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (450 unité)

Documents et téléchargements

description

EBM-PAPST - 4114NHH - DC Axial Fan, 24 V, Square, 119 mm, 38 mm, Ball Bearing, 152.9 CFM

  • Supply Voltage: 24V
  • Current Type: DC
  • Fan Frame Size: 119mm
  • External Depth: 38mm
  • Noise Rating: 60dBA
  • Flow Rate - Imperial: 152.9cu.ft/min
  • Flow Rate - Metric: 260m³/h
  • Bearing Type: Ball
  • Power Connection Type: 2 Lead Wires
  • Current Rating: -
  • Product Range: 4100N Series
  • Power Rating: 15.5W
  • IP Rating: IP20
  • SVHC: No SVHC (15-Jan-2019)
  • Approval Bodies: CE
  • Case Material: Metal
  • External Height: 119mm
  • External Width: 119mm
  • Frame Dimensions: 119mm x 119mm x 38mm
  • Input Voltage Max: 15VDC
  • Input Voltage Min: 9VDC
  • Lead Length: 310mm
  • Material: Fiberglass-reinforced PA plastic
  • Operating Temperature Max: 65°C
  • Operating Temperature Min: -20°C
  • Power Consumption: 12.4W
  • Speed Range Max: 5000rpm
  • Supply Voltage DC Max: 30VDC
  • Supply Voltage DC Min: 16V
  • Type: Reverse polarity protection
  • Weight: 390g
