FINDER - 41.61.9.024.0010 - General Purpose Relay, 41 Series, Power, SPDT, 24 VDC, 16 A
- Contact Configuration: SPDT
- Coil Voltage: 24VDC
- Contact Current: 16A
- Product Range: 41 Series
- Relay Mounting: Through Hole
- Coil Type: -
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: -
- Contact Material: Silver Nickel
- Coil Resistance: 1.44kohm
- SVHC: No SVHC (15-Jan-2019)
- Approval Bodies: CSA, UL, VDE
- Coil Current: 19.7mA
- Coil Operating Lower Percent Limit: 150%
- Coil Operating Upper Percent Limit: 75%
- Coil Voltage VDC Nom: 24V
- Contact Current AC Max: 16A
- Contact Current DC Max: 16A
- Contact Current Max: 30A
- Contact Resistance: 1440ohm
- Contact Voltage AC Max: 250V
- Contact Voltage AC Nom: 250V
- DC Coil Power: 400mW
- External Depth: 29mm
- External Height: 15.7mm
- External Length / Height: 15.7mm
- External Width: 12.7mm
- Nom Operating Power: 400mW
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Operating Time: 5ms
- Relay Type: Power
- Release Time: 4ms
