BOURNS - 4606X-102-104LF - Fixed Network Resistor, 100 kohm, Isolated, 3 Resistors, SIP, PC Pin, ± 2%
- Resistance: 100kohm
- Product Range: 4600X Series
- No. of Elements: 3Elements
- Network Circuit Type: Isolated
- Resistor Case Style: SIP
- No. of Pins: 6Pins
- Voltage Rating: 100V
- Power Rating per Element: 300mW
- Resistance Tolerance: ± 2%
- Temperature Coefficient: ± 100ppm/°C
- Automotive Qualification Standard: -
- SVHC: Lead (15-Jan-2019)
- External Depth: 5.08mm
- External Length / Height: 15.19mm
- External Width: 2.49mm
- Full Power Rating Temperature: 70°C
- Insulation Resistance: 10Mohm
- Lead Length: 3.43mm
- Lead Spacing: 2.54mm
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +125°C
- Power Rating: 750mW
- Resistance R1: 100kohm
- Resistor Element Material: Thick Film
- Resistor Mounting: Through Hole
- Resistor Terminals: Radial Leaded
- Temperature Coeff Tracking +: 50ppm/°C
- Temperature Coeff Tracking -: 50ppm/°C
- Temperature Coeff. +: 100ppm/°C
- Temperature Coeff. -: 100ppm/°C
- Tolerance +: 2%
- Tolerance -: 2%
- Voltage Rating V DC: 100V
