FINDER - 55.12.8.024.0000 - General Purpose Relay, 55 Series, Power, DPDT, 24 VAC, 10 A
- Contact Configuration: DPDT
- Coil Voltage: 24VAC
- Contact Current: 10A
- Product Range: 55 Series
- Relay Mounting: Through Hole
- Coil Type: -
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: -
- Contact Material: Silver Nickel
- Coil Resistance: 190ohm
- SVHC: No SVHC (15-Jan-2019)
- Approvals & Standards: CSA, UL, VDE
- Coil Current: 53mA
- Coil Voltage VAC Nom: 24V
- Contact Current AC Max: 20A
- Contact Current Max: 20A
- Contact Current Rating: 10A
- Contact Voltage AC Max: 400V
- Contact Voltage AC Nom: 250V
- Dielectric Voltage Contact to Contact: 1000VAC
- External Depth: 27.7mm
- External Height: 35.3mm
- External Length / Height: 35.3mm
- External Width: 20.7mm
- No. of Electrical Operations: 200000
- No. of Mechanical Operations: 20000000
- Nom Operating Power: 1.5VA
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Operating Time: 9ms
- Relay Type: Power
- Release Time: 3ms
- Supply Voltage AC Max: 26.4V
- Supply Voltage AC Min: 19.2V
- Voltage Rating VAC: 250V
