FINDER - 55.34.9.110.0040 - General Purpose Relay, 55 Series, Power, 4PDT, 110 VDC, 7 A
- Contact Configuration: 4PDT
- Coil Voltage: 110VDC
- Contact Current: 7A
- Product Range: 55 Series
- Relay Mounting: Socket
- Coil Type: -
- Contact Voltage VAC: 250VAC
- Relay Terminals: Quick Connect
- Contact Voltage VDC: -
- Contact Material: Silver Nickel
- Coil Resistance: 12.5kohm
- SVHC: No SVHC (15-Jan-2019)
- AC Coil Power: 1.5VA
- Approval Bodies: CSA, IMQ, SEMKO, SEV, UL, VDE
- Approvals & Standards: CSA, UL, VDE
- Coil Current: 8.8mA
- Coil Operating Lower Percent Limit: 80%
- Coil Operating Upper Percent Limit: 110%
- Coil Voltage VDC Nom: 110V
- Contact Current AC Max: 7A
- Contact Current Max: 15A
- Contact Voltage AC Max: 250V
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Max: 121V
- DC Coil Power: 1W
- External Depth: 33.5mm
- External Height: 27.5mm
- External Length / Height: 27.5mm
- External Width: 20.6mm
- Nom Operating Power: 1W
- Operating Temperature Max: 70°C
- Operating Temperature Min: -40°C
- Operating Time: 9ms
- Relay Type: Power
- Release Time: 3ms
