BERNSTEIN - 608-8867-010 - Limit Switch, Roller Lever, 2NC, 10 A, 250 V, 7 N, Tiny Ti2
- Limit Switch Actuator: Roller Lever
- Contact Configuration: 2NC
- Contact Current AC Max: 10A
- Contact Voltage AC Max: 250V
- Operating Force Max: 7N
- Product Range: Tiny Ti2 Series
- Contact Current DC Max: -
- Contact Voltage DC Max: -
- SVHC: No SVHC (15-Jan-2019)
- Actuator Type: Roller Plunger
- Case Material: Thermoplastic
- Contact Current Rating: 10A
- External Depth: 27mm
- External Length / Height: 45mm
- External Width: 30mm
- IP / NEMA Rating: IP65
- Inrush Current Max: IEC 947-5-1, AC 15, DC 13
- No. of Mechanical Operations: 3000000
- Operating Temperature Max: 80°C
- Operating Temperature Min: -30°C
- Switch Operation: Off-On
- Switch Terminals: Screw
- Thermal Current Rating: 10A
